Chili dryer
Made in China, Serving the World！ If you want to know more about the application of [Chili dryer] product new technology in practice, please call JUSUNG [Chili dryer] technical consultation for more practical information!
Product advantage of Chili dryer
1. Large output: The dryer adopts multi-layer cyclic dynamic drying mode, which can be processed 24 hours by mass drying.
2. High quality: the dried pepper has bright color, complete shape, strong spicy flavor and moderate moisture, which is trusted by users.
3. Intelligent and accurate: The use of intelligent control system can ensure the temperature, time, air volume and other parameters control in the drying process.
4. cost saving: only one person can complete the whole equipment, drying time is also shortened, saving labor and time cost.
5. High heat energy conversion rate: Independently developed heat exchange device, which can be matched with various heat sources, the heat energy conversion rate is as high as 95%.
6. clean health: the whole drying process is completed in the closed box, will not be polluted by the outside world.
7. long equipment life: the overall running speed of the dryer is very slow, almost no wearing parts, in normal use, the service life is as long as ten to fifteen years or more.
Technical parameter of Chili dryer
|
Dryer model number |
Spreading area |
Handling capacity |
Total power |
Floor area (length * width * height) |
|
2 x 6 meters x 4 layers |
40㎡ |
3tons |
15kw |
20*5*3.5meters |
|
2 x 8 meters x 4 layers |
56㎡ |
5tons |
23kw |
22*5*3.5meters |
|
2 x 10 meters x 4 layers |
72㎡ |
7tons |
28kw |
26*5*3.5meters |
|
2 x 12 meters x 4 layers |
88㎡ |
9tons |
37kw |
28*5*3.5meters |
|
2 x 15 meters x 4 layers |
112㎡ |
12tons |
64kw |
31*5*3.5meters |
|
2 x 20 meters x 4 layers |
152㎡ |
15tons |
86kw |
36*5*3.5meters |
|
2.5 x 12 meters x 6 layers |
165㎡ |
16tons |
55kw |
30*6*3.5meters |
|
2.5 x 15 meters x 6 layers |
210㎡ |
18tons |
75kw |
33*6*3.5meters |
|
2.5 x 20 meters x 6 layers |
285㎡ |
22tons |
103kw |
38*6*3.5meters |
|
2.5 x 25 meters x 6 layers |
360㎡ |
25tons |
108kw |
43*6*3.5meters |
|
2.5 x 30 meters x 6 layers |
435㎡ |
30tons |
130kw |
48*6*3.5meters |
|
Note: Coal or biomass is used as heat source, and chili is used as raw material. |
||||
Good products in China, serving customers of major continents！ JUSUNG For many years has adhered to the Food, Metallurgy, Chemical industry, Textile, Agriculture and Animal husbandry field and polished "craftsman" level talents on Chili dryer and other products!
